Marking Thickness Gauge
Marking Thickness Gauge Marking Thickness Gauge
Marking Thickness Gauge Marking Thickness Gauge

loading

Marking Thickness Gauge

Share to:
sharethis sharing button
This handheld thickness gauge is an instrument for measuring the thickness of pavement marking, with OLED display, it can be used in both laboratory and on site. It is applicable to quality control and inspection of marking coating thickness for road maintenance units, road marking lacquer manufacturers, construction companies, quality supervision department.
  • TBTRMT-1

  • TBTSCIETECH

Availability:

Technical Specification

No.

Description of goods

Technical specification

1

Measuring range

+/-13mm

2

Measuring resolution

0.01mm

3

Accuracy

0.02mm

4

Calibration block accuracy

Grade 00

5

Displayer

OLED

6

Li-battery working time

>30hr continously

7

Power supply

12V 5.2Ah

8

Working temp. & humidity

-15C ~ 60C / <98%

9

Dimension

Around 140*110*30mm




























     Main Features

Small volume, easy to carry, single hand operation

OLED display to show data more clearer

Built-in large capacity lithium battery, long standby time

00 level marble demarcation board, more accurate data measurement

Aluminum alloy profile, precision double guide, stable and durable

Switch off automatically to save power
