TBTWB-2
TBTSCIETECH
| Availability: | |
|---|---|
The instrument adopts the new-type refrigeration compressor unit with good effective cooling,low noise,is widely welcome by operators of test units and laboratories.It has big volume,high precision temperature control,and is especially suitable to use in highway engineering laboratories.
The instrument adopts the new-type refrigeration compressor unit with good effective cooling,low noise,is widely welcome by operators of test units and laboratories.It has big volume,high precision temperature control,and is especially suitable to use in highway engineering laboratories.
1. With stainless steel water container and operating platform,spraying plastic tank,strong anti-corrosion and wear well.
2. With high precision LCD display temperature controller,circulating pump to ensure the liquid circulation of water bath,completely circulation,uniform temperature in bath.
3. With three work modes:
(1).Self-circulating cold bath mode to control temperature and keep warm of different bituminous mixture sample.
(2).External connecting closed-loop system mode to contro temperature and keep warm of different closed-loop system.
(3).External connecting penetrometer professional cold bath mode, separately buy the penetrometer professional cold bath to control temperature and keep warm.
4. Big volume,reasonable design,convenient operation.
1. With stainless steel water container and operating platform,spraying plastic tank,strong anti-corrosion and wear well.
2. With high precision LCD display temperature controller,circulating pump to ensure the liquid circulation of water bath,completely circulation,uniform temperature in bath.
3. With three work modes:
(1).Self-circulating cold bath mode to control temperature and keep warm of different bituminous mixture sample.
(2).External connecting closed-loop system mode to contro temperature and keep warm of different closed-loop system.
(3).External connecting penetrometer professional cold bath mode, separately buy the penetrometer professional cold bath to control temperature and keep warm.
4. Big volume,reasonable design,convenient operation.
1. Power supply | 220VAC 50HZ |
2. Volume of water bath | 330㎜×390㎜×300㎜（L×W×H） |
3.Applicable water yield | 32L |
4. Heating device | Electric heater,power 1500W |
5.Cooling device | New-type environment friendly compressor |
6. Temperature control range | -10℃～70℃ |
7. Temperature control accuracy | ±0.1 ℃ |
8. Ambient temperature | ≤30℃ |
9. Relative humidity | ≤85% |
10. Total consumption | Less 2300W |
11. Outline dimension | 530㎜×520㎜×1000㎜（L×W×H） |
12.Net weight | 40㎏ |
Note:Penetrometer professional cold bath is optional
1. Power supply | 220VAC 50HZ |
2. Volume of water bath | 330㎜×390㎜×300㎜（L×W×H） |
3.Applicable water yield | 32L |
4. Heating device | Electric heater,power 1500W |
5.Cooling device | New-type environment friendly compressor |
6. Temperature control range | -10℃～70℃ |
7. Temperature control accuracy | ±0.1 ℃ |
8. Ambient temperature | ≤30℃ |
9. Relative humidity | ≤85% |
10. Total consumption | Less 2300W |
11. Outline dimension | 530㎜×520㎜×1000㎜（L×W×H） |
12.Net weight | 40㎏ |
Note:Penetrometer professional cold bath is optional
No. | Name | Unit | Qty |
1 | Thermostatic Water Bath | Set | 1 |
2 | Stainless steel cover | Piece | 1 |
3 | Fuse 15A （φ5×20） | Piece | 2 |
4 | Silicon gel tube—outer diameter 12 mm,inner diameterΦ8mm （Self-cycling using） | Meter | 0.6 |
5 | Sponge insulated pipe （Self-cycling using） | Meter | 0.6 |
6 | Silicon gel tube—outer diameter 12 mm,inner diameter Φ8mm （External circulating using） | Meter | 1.8 |
7 | Sponge insulated pipe （External circulating using）
| Meter | 1.8 |
8 | Converting connector | Set | 2 |
9 | Operation manual | Piece | 1 |
10 | Quality certificate | Piece | 1 |
11 | Repair guarantee | Piece | 1 |
No. | Name | Unit | Qty |
1 | Thermostatic Water Bath | Set | 1 |
2 | Stainless steel cover | Piece | 1 |
3 | Fuse 15A （φ5×20） | Piece | 2 |
4 | Silicon gel tube—outer diameter 12 mm,inner diameterΦ8mm （Self-cycling using） | Meter | 0.6 |
5 | Sponge insulated pipe （Self-cycling using） | Meter | 0.6 |
6 | Silicon gel tube—outer diameter 12 mm,inner diameter Φ8mm （External circulating using） | Meter | 1.8 |
7 | Sponge insulated pipe （External circulating using）
| Meter | 1.8 |
8 | Converting connector | Set | 2 |
9 | Operation manual | Piece | 1 |
10 | Quality certificate | Piece | 1 |
11 | Repair guarantee | Piece | 1 |
