Bitumen ASTM Automatic Binder Extractor for Bitumen Content is suitable to determine bitumen content (bitumen-mineral aggregate ratio) in the bituminous mixture, which is made of viscous petroleum bitumen, by the centrifuge separation method. It is an ideal instrument for pavement construction units, detection unit, scientific research institutions and colleges.
Bitumen ASTM Automatic Binder Extractor for Bitumen Content is suitable to determine bitumen content (bitumen-mineral aggregate ratio) in the bituminous mixture, which is made of viscous petroleum bitumen, by the centrifuge separation method. It is an ideal instrument for pavement construction units, detection unit, scientific research institutions and colleges.
1.Floor-type structure. It is a fully-automatic and intelligent instrument for testing the bitumen content in the bituminous mixture.
2.Micro-processing technology, with LCD touch screen which is easy to operate.
3. Includes of three main parts: Sieving, Centrifuge extracting, Solvent recovery;
1.Floor-type structure. It is a fully-automatic and intelligent instrument for testing the bitumen content in the bituminous mixture.
2.Micro-processing technology, with LCD touch screen which is easy to operate.
3. Includes of three main parts: Sieving, Centrifuge extracting, Solvent recovery;
1. Capacity | 1000g~1500g |
2. Extracting precision | ≤0.1% |
3. Extracting time | (20~40)minutes per time |
4. Centrifuging speed | 5500r.p.m, 11000r.p.m |
5. Working environment | (5~40)℃，RH﹤80% |
6. Power supply | AC380V±10%, 50 Hz |
7. Maximum power consumption | About 5kw |
8. Net weight | About 300kg |
9. Dimension | 1400㎜(L)×800㎜(W)×1600㎜(H) |
1. Capacity | 1000g~1500g |
2. Extracting precision | ≤0.1% |
3. Extracting time | (20~40)minutes per time |
4. Centrifuging speed | 5500r.p.m, 11000r.p.m |
5. Working environment | (5~40)℃，RH﹤80% |
6. Power supply | AC380V±10%, 50 Hz |
7. Maximum power consumption | About 5kw |
8. Net weight | About 300kg |
9. Dimension | 1400㎜(L)×800㎜(W)×1600㎜(H) |
No. | Item | Unit | Qty | Remarks |
1 | Conical sieve | Set | 1 | It has been installed in the instrument |
2 | "○" type sealing ring (￠122×3.55) | Piece | 1 | It has been installed in the instrument |
3 | Centrifugal cylinder | Piece | 1 | It has been installed in the instrument |
4 | Centrifugal cylinder handle | Piece | 1 | |
5 | Filter paper (385 × 200 × 0.10) | Piece | 500 | |
6 | Plastic pipes | Meter | 10 | |
7 | Funnel | Piece | 1 |
No. | Item | Unit | Qty | Remarks |
1 | Conical sieve | Set | 1 | It has been installed in the instrument |
2 | "○" type sealing ring (￠122×3.55) | Piece | 1 | It has been installed in the instrument |
3 | Centrifugal cylinder | Piece | 1 | It has been installed in the instrument |
4 | Centrifugal cylinder handle | Piece | 1 | |
5 | Filter paper (385 × 200 × 0.10) | Piece | 500 | |
6 | Plastic pipes | Meter | 10 | |
7 | Funnel | Piece | 1 |
