Distillation Stove

Share to:

It is the specified equipment and matched with the “TBT-0615 Asphalt Wax Content Tester”,It also satisfies the needs of petroleum products .

  • TBT-0615-1
  • TBTSCIETECH

The instrument is designed and made as per the regulation of cracking distillation stove in the petrochemical industrial standard of People's Republic of China SH/T 0425-2003 “Test Method for Wax content of the Asphalt ” and T0615-2011 “Asphalt Wax Content Test (Distillation Method)” in the industrial standard of People’s Republic of China JTG E20-2011 “Standard Test Methods of Bitumen and Bituminous Mixture for Highway Engineering ”


1. This instrument adopts the mode of electric heating ,and the constant temperature can be  controlled the range of 550℃+10℃.The heating power can be adjusted continuously and it can satisfy the needs of the distillation of samples .

2. The instrument adopts heating furnace and elevator-platform.Two parts are independently and in use two is made one ,it is convenient to use .

3. The housing washer of heating furnace adopts humanized design of heat insulation and reduce the effect of the heat radiation to the operator .

4. The temperature controller adopts LCD display, single chip control technology. Advanced technology and small overshoot .It can reach to 550℃+10℃constant temperature ,which only needs 15 minutes at normal atmospheric temperature.


Power supply

 AC(220±10%)V, 50 Hz

The electric furnace heating power

 2000W

Heating control

 solid adjustable pressure model can be adjusted continuously.

Constant temperature control

 550℃+10℃

Ambient temperature

 ≤35℃

Relative humidity

 ≤85%

Total power consumption

≤2100W

Dimension

heating furnace: 220mm*330mm*400mm, elevator-platform:150mm*1750mm*120mm

Weight

 5kg


No.

Item

Unit

Qty

1

Lifting platform

Set

1

2

Column

Piece

1

3

Clamp holder

Piece

1

4

Electric furnace cover

Piece

1

5

15A fuse(Ф5×20)

Piece

2
